S721RG
- WH : White
- COLOR VARIATION：
COLOR VARIATION
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
SPEC
-
SPECS
- neck type
- Wizard III5pc Maple/Walnut neck
- top/back/body
- Okoume body
- fretboard
- Ebony fretboardOff-set ring inlay
- fret
- Jumbo frets
- number of frets
- 24
- bridge
- Gibraltar Standard III bridge
- string space
- 10.8mm
- neck pickup
- Fishman® Fluence™ Modern Humbucker Alnico (H) neck pickupActive/Alnico
- bridge pickup
- Fishman® Fluence™ Modern Humbucker Ceramic (H) bridge pickupActive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- hardware color
- Gold
-
NECK DIMENSIONS
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 19mm at 1F
- d : Thickness
- 21mm at 12F
- Radius :
- 400mmR
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard -
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is a three-way pickup selector switch near to the knee cutout of the guitar. The knob right above the pickup selector switch is the volume knob. The volume knob also functions as a Fishman Fluence voicing switch. When the knob is down, the pickups are in voice 1, and when the knob is up, the pickups are in voice 2.
-
OTHER FEATURES
Features
Wizard III 5pc Maple/Walnut neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
Ebony fretboard
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
Jumbo frets
Jumbo frets contribute to smooth playability, especially for single-note playing.
Fishman® Fluence™ Modern Humbucker Ceramic pickups
The Fishman® Fluence™ Modern Humbucker pickups provide an aggressive tone and a powerful attack without excess noise.
Locking machine heads
Locking machine heads ensure accurate and stable tuning.
Gibraltar Standard III bridge
The Gibraltar Standard III bridge, featuring a redesigned baseplate and saddles, offers enhanced playing comfort while ensuring optimal string vibration transfer.
Okoume body
The Okoume body provides a bright and solid sound.
Fishman® Fluence™ Voicing switch on volume control (push/pull)
The Voicing switch allows the pickups to switch from a modern, active high output sound to a crisp, clean and fluid sound.
Luminescent side dots
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
