GSRM20
SPEC
-
SPECS
- neck type
- GSRM4Maple neck
- top/back/body
- Poplar body
- fretboard
- Bound Purpleheart fretboardWhite dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- B10 bridge
- string space
- 19mm
- neck pickup
- Dynamix P neck pickupPassive
- bridge pickup
- Dynamix J bridge pickupPassive
- factory tuning
- 1G,2D,3A,4E
- string gauge
- .045/.065/.085/.105
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 726mm/28.6"
- a : Width
- 38mm at NUT
- b : Width
- 58.5mm at 22F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 22mm at 12F
- Radius :
- 350mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
CONTROLS
DESCRIPTION
With the bass held in the playing position, from the end of the body towards the direction of the neck, the controls are, tone, bridge pickup volume, and neck pickup volume.
-
OTHER FEATURES
- Recommended Bag
-
IBBMIKRO
Features

Maple neck
The Maple neck provides stability and bright tonal character.

Purpleheart fretboard
The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this bass.

B10 series bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.

Size Comparison
