GA11CE
- BK : Black High Gloss
- COLOR VARIATION：
SPEC
-
SPECS
- body shape
- Cutaway Classical body
- top
- Spruce top
- back & sides
- Sapele back & Sapele sides
- neck
- GAOkoume neck
- fretboard
- Purpleheart fretboard
- bridge
- Purpleheart bridge
- soundhole rosette
- Classical Mosaic Design rosette
- tuning machine
- Gold Classical tuners
- number of frets
- 19
- string gauge
- .0285/.0325/.041/.030/.036/.044
- string space
- 11.6mm
- factory tuning
- 1E,2B,3G,4D,5A,6E
- pickup
- Ibanez Undersaddle pickup
- preamp
- Ibanez AEQ-TP2 preamp w/Onboard tuner
- output jack
- 1/4" output
- battery
- 9V x1
-
NECK DIMENSIONS
-
- Scale :
- 650mm/25.6"
- a : Width
- 52mm at NUT
- b : Width
- 63.5mm at 14F
- c : Thickness
- 22mm at 1F
- d : Thickness
- 24mm at 7F
- Radius :
- Flat
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
BODY DIMENSIONS
-
- a : Length
- 19 3/8"
- b : Width
- 14 1/2"
- c : Max Depth
- 3 7/8"
-
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body
-
-
PREAMP
DESCRIPTION
The neck side of the preamp is the top of the control panel. There is one button switch and three knobs towards the top of the control panel. The button furthest left is the tuner on/off switch. To the right of that are the bass, treble, and volume knobs.
-
OTHER FEATURES
Features
Okoume neck
The Okoume neck provides greater playing comfort.
Purpleheart fretboard
The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this instrument.
Spruce top
Spruce remains the most popular wood for acoustic guitar tops, mainly due to its pristine tonal clarity.
Sapele back and sides
Sapele back and sides offer a full-bodied and warm mid-range and a bright tone.
Ibanez Undersaddle pickup
The Ibanez Undersaddle Pickup accurately reproduces the acoustic nature of the bass.
Purpleheart bridge
The Purpleheart bridge transfers string vibration directly to the body, delivering a natural and warm tone.
Ibanez AEQ-TP2 preamp w/Onboard tuner
The Ibanez AEQ-TP2 preamp provides the extra punch of on-board EQ along with a convenient and easy-to-read digital tuner and 2-band EQ, located on the instrument’s upper bout.
