AFB200

SPEC

SPECS
- neck type
- AFB43pc Nyatoh/Mapleset-in neck
- top/back/body
- Linden topLinden backLinden sides
- fretboard
- Bound Walnut fretboardWhite dot inlay
- fret
- Medium frets
- number of frets
- 22
- bridge
- ART-1 wooden bridge
- string space
- 19mm
- tailpiece
- FBT40 tailpiece
- neck pickup
- Classic Elite Bass neck pickupPassive
- bridge pickup
- Classic Elite Bass bridge pickupPassive
- factory tuning
- 1G,2D,3A,4E
- string gauge
- .050/.070/.085/.105
- hardware color
- Chrome
NECK DIMENSIONS
- - Scale :
  - 770mm/30.3"
  - a : Width
  - 42mm at NUT
  - b : Width
  - 61mm at 22F
  - c : Thickness
  - 21.5mm at 1F
  - d : Thickness
  - 24mm at 9F
  - Radius :
  - 400mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
CONTROLS

DESCRIPTION

With the bass held in the playing position, the pickup selector switch is the control closest to the lower edge of the body. Just above the selector switch, there are two knobs arranged diagonally. The knob closest to the input jack is the tone knob. The knob closest to the neck is the volume knob.
OTHER FEATURES
- Recommended Bag
- IABB540-BK

Classic Elite Bass Pickups deliver classic tone, punch and extra output.
