TOD

SPEC

SPECS
- body shape

  FRH chambered body
- bracing

  Fan Bracing for Chambered FRH body
- top

  Solid Sitka Spruce top
- back & sides

  Solid Okoume back & Solid Okoume sides
- neck

  C shapeNyatohSet-in neck
- fretboard

  Ebony fretboard
- bridge

  Ebony double hole bridge
- body binding

  Rosewood body binding
- inlay

  Tree of Death inlay
- tuning machine

  Gold Classical tuners
- number of frets

  22
- strings

  D'Addario® XTC45
- string gauge

  .028/.032/.040/.028W/.035W/.044W
- string space

  11.1mm
- factory tuning

  1E,2B,3G,4D,5A,6E
- pickup

  Fishman® Acoustic Matrix™ Undersaddle Pickup, Fishman® Bridge Mounted Body Pickup
- preamp

  Fishman® Aura® Preamp
- output jack

  1/4" Output (Mono or Stereo)
- battery

  9V x1
NECK DIMENSIONS
- - Scale :

    651mm/25.6"
  - a : Width

    46mm at NUT
  - b : Width

    58mm at 14F
  - c : Thickness

    21mm at 1F
  - d : Thickness

    22mm at 7F
  - Radius :

    400mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
BODY DIMENSIONS
- - a : Length

    17 1/2"
  - b : Width

    13 15/16"
  - c : Max Depth

    1 15/16"
- DESCRIPTION

  Guitar Body Diagram
  A: Length of the body
  B: Maximum width of the body
  C: Maximum depth of the body
OTHER FEATURES
- Available in Summer 2026
- TOD100N comes with THGB1 (Tim Henson Signature Gig Bag).
- 400mmR fretboard radius
- Side Sound Port
