TMB100
SPEC
-
SPECS
-
neck typeTMB4Maple neck
-
top/back/bodyPoplar body
-
fretboardJatoba fretboardWhite dot inlay
-
fretMedium frets
-
number of frets20
-
bridgeB10 bridge
-
string space19mm
-
neck pickupDynamix P neck pickupPassive
-
bridge pickupDynamix J bridge pickupPassive
-
equaliserIbanez Custom Electronics 2-band EQ
-
factory tuning1G,2D,3A,4E
-
string gauge.045/.065/.080/.100
-
hardware colorChrome
-
-
NECK DIMENSIONS
-
-
Scale :864mm/34"
-
a : Width41mm at NUT
-
b : Width62mm at 20F
-
c : Thickness21.5mm at 1F
-
d : Thickness24.5mm at 12F
-
Radius :240mmR
-
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
CONTROLS
DESCRIPTION
There are two stacked knobs on this bass. The top knob of the stack closest to the end of the body is the treble boost/cut control, and the lower knob is the bass boost/cut control. The top knob of the stack closest to the neck is the volume control, and the lower knob is pickup balancer.
-
FREQUENCY RESPONSE
DESCRIPTION
The bass boost/cut frequency curve has a peak at 20 Hz and a variable width that decreases toward the high range, and a curve that the variable width becomes zero at approximately 1000 Hz. The variable range becomes slightly larger in the high range than around 1000 Hz, but it becomes zero again near 5000 Hz. The variable range of the peak frequency is approximately ±15 dB. The treble boost/cut frequency curve creates a bell-shaped curve with a peak around 10000 Hz and zero variable range around 100 Hz. The variable range of the peak frequency is approximately ±15 dB.
-
OTHER FEATURES
- Recommended Case
- MRB350C
Features
Maple neck
The Maple neck provides stability and bright tonal character.
Dynamix pickups
The Ibanez DXP neck pickup and DXJ bridge pickup provide the rich, vintage sound.
Ibanez Custom Electronics 2-band EQ
The Ibanez Custom Electronics 2-band EQ offers a wide range of sounds.
B10 bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
