S6521Q

S6521Q-SLG
  • SLG : Surreal Blue Burst Gloss
  • COLOR VARIATION：

Top of the S6521Q-SLG's body
Back of the S6521Q-SLG's body
Entire top of the S6521Q-SLG
Entire back of the S6521Q-SLG
S

SPEC

  • SPECS

    • neck type
      Super Wizard HP 5pc Maple/Walnut neck w/KTS™ TITANIUM rods
    • top/back/body
      Quilted Maple topAfrican Mahogany body
    • fretboard
      Bound Macassar Ebony fretboardOff-set white dot inlay
    • fret
      Jumbo fretsPrestige fret edge treatment
    • number of frets
      24
    • bridge
      Gibraltar Standard II bridge
    • string space
      10.8mm
    • neck pickup
      DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
    • bridge pickup
      DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
    • factory tuning
      1E,2B,3G,4D,5A,6E
    • strings
      D'Addario® EXL110
    • string gauge
      .010/.013/.017/.026/.036/.046
    • nut
      Graph Tech® BLACK TUSQ XL®
    • hardware color
      Cosmo black

  • NECK DIMENSIONS

      • Scale :
        648mm/25.5"
      • a : Width
        43mm at NUT
      • b : Width
        58mm at 24F
      • c : Thickness
        17mm at 1F
      • d : Thickness
        19mm at 12F
      • Radius :
        430mmR

    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the fret position specified by the neck dimension
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the fret position specified by the neck dimension
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    S6521Q's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.

  • CONTROLS

    S6521Q's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

  • OTHER FEATURES

    • Gotoh® MG-T locking machine heads
    • Hardshell case included

Features

Super Wizard 5pc Maple/Walnut neck

Super Wizard 5pc Maple/Walnut neck

The Super Wizard 5pc Maple/Walnut neck provides extra-smooth playing.

Macassar Ebony fretboard

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Gibraltar Standard II Bridge

Gibraltar Standard II bridge

The Gibraltar Standard II is a simple fixed bridge designed provide optimal transfer of each string's vibration and its smooth surface maximizes playing comfort.

DiMarzio Pickups

DiMarzio® pickups

A pair of high-output DiMarzio Air Norton™ and The Tone Zone® pickups provides a huge sound with a broad dynamic range.

Gotoh MG-T locking machine heads

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
