RG652AHM

PHOTOS
SPEC
FEATURES
SUPPORT

NGB : Nebula Green Burst
AWD : Antique White Blonde

COLOR VARIATION：

COLOR VARIATION

SPEC

SPECS
- neck type

  Super Wizard HP5pc Maple/Walnut neck
- top/back/body

  Ash body
- fretboard

  Bound Birdseye MapleBlack dot inlay
- fret

  Jumbo frets
- bridge

  Edge tremolo bridge
- string space

  10.8mm
- neck pickup

  DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
- bridge pickup

  DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
- factory tuning

  1E, 2B, 3G, 4D, 5A, 6E
- strings

  D'Addario® EXL120
- string gauge

  .009/.011/.016/.024/.032/.042
- hardware color

  Cosmo black
NECK DIMENSIONS
- Scale :

  648mm/25.5"
- a : Width

  43mm at NUT
- b : Width

  58mm at 24F
- c : Thickness

  17mm at 1F
- d : Thickness

  19mm at 12F
- Radius :

  430mmR
DESCRIPTION

Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
SWITCHING SYSTEM

DESCRIPTION

When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
CONTROLS

DESCRIPTION

With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
OTHER FEATURES
- Hardshell case included
