RG5320C-DFM
  • DFM : Deep Forest Green Metallic
  • COLOR VARIATION:
RG

SPEC

  • SPECS

    • neck type
      Super Wizard HP5pc Maple/Wenge neck
    • top/back/body
      African Mahogany body
    • fretboard
      Bound Macassar Ebony fretboardOff-set Mother of Pearl dot inlay
    • fret
      Jumbo Stainless Steel fretsPrestige fret edge treatment
    • number of frets
      24
    • bridge
      Lo-Pro Edge bridge
    • string space
      10.8mm
    • neck pickup
      DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico
    • bridge pickup
      DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico
    • factory tuning
      1E,2B,3G,4D,5A,6E
    • strings
      D'Addario® EXL120
    • string gauge
      .009/.011/.016/.024/.032/.042
    • nut
      Locking nut
    • hardware color
      Chrome
  • NECK DIMENSIONS

      • Scale :
        648mm/25.5"
      • a : Width
        43mm at NUT
      • b : Width
        58mm at 24F
      • c : Thickness
        17mm at 1F
      • d : Thickness
        19mm at 12F
      • Radius :
        430mmR
    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the fret position specified by the neck dimension
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the fret position specified by the neck dimension
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    RG5320C's Switching system diagram

    DESCRIPTION

    When the coil tap switch is in neck position, coil tap is on. When the coil tap switch is in bridge position, coil tap is off. When coil tap is off and the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both neck and bridge pickups are selected. When the switch is in the bridge position, the bridge pickup is selected. When coil tap is on and the pickup selector switch is in the neck position, the bridge side of the neck pickup is selected. When the switch is in center position, the bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, neck side of the bridge pickup is selected.

  • CONTROLS

    RG5320C's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the knee cut out is a three-way pickup selector switch. Closest to the end of the body is the tone knob. The volume knob is located right above the three-way pickup selector switch. Between the volume and tone knobs is a coil tap switch. When the switch is in the neck position, the coil tap is on. When the switch is in the bridge position, the coil tap is off.

  • OTHER FEATURES

    • Hardshell case included
    • Coil-tap switch
    • Luminlay side dots
    • Gotoh® machine heads

Features

Super Wizard HP 5pc Maple/Wenge neck

Super Wizard HP 5pc Maple/Wenge neck

Super Wizard 5pc Maple/Wenge neck provides extra-smooth playing.

Macassar Ebony fretboard

Macassar Ebony fretboard

Macassar Ebony produces tight lows and mid range along with strong attack in the highs and quick response with rich sustain.

Lo-Pro Edge tremolo bridge

Lo-Pro Edge tremolo bridge

The legendary Lo-Pro Edge bridge offers maximum playing comfort with its streamlined profile and recessed fine tuners. Locking studs contribute to tuning stability.

DiMarzio Pickups

DiMarzio® pickups

A pair of high-output DiMarzio Air Norton™ and The Tone Zone® pickups provides a huge sound with a broad dynamic range.

Coil-tap switch

Coil-tap switch

The coil tap switch adds sound and tonal variations for both pickups.

Luminlay side dot inlays

Luminlay side dot inlays

The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Gotoh® machine heads

Gotoh® machine heads

Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.
