RG5121ET

PHOTOS
SPEC
FEATURES
SUPPORT

PRT : Polar Lights

COLOR VARIATION：

SPEC

SPECS
- neck type

  Super Wizard HP5pc Maple/Wenge neck
- top/back/body

  African Mahogany body
- fretboard

  Bound Macassar Ebony fretboardOff-set Mother of Pearl dot inlay
- fret

  Jumbo Stainless Steel fretsPrestige fret edge treatment
- number of frets

  24
- bridge

  Evertune® bridge
- string space

  10.3mm
- neck pickup

  Fishman® Fluence™ Modern Humbucker Ceramic (H) neck pickupActive/Ceramic
- bridge pickup

  Fishman® Fluence™ Modern Humbucker Ceramic (H) bridge pickupActive/Ceramic
- factory tuning

  1E,2B,3G,4D,5A,6E
- strings

  D'Addario® EXL110
- string gauge

  .010/.013/.017/.026/.036/.046
- nut

  Graph Tech® BLACK TUSQ XL® nut
- hardware color

  Black
NECK DIMENSIONS
- - Scale :

    648mm/25.5"
  - a : Width

    43mm at NUT
  - b : Width

    58mm at 24F
  - c : Thickness

    17mm at 1F
  - d : Thickness

    19mm at 12F
  - Radius :

    430mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
SWITCHING SYSTEM

DESCRIPTION

When the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.
CONTROLS

DESCRIPTION

With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the knee cutout is a three-way pickup selector switch. Closer to the end of the body is the tone knob. The volume knob is located right above the three-way pickup selector switch. Between the volume and tone knobs is a Fishman Fluence voicing switch. When the switch is in the neck position, the pickup is set to voicing 2. When the switch is in the bridge position, the pickup is set to voicing 1.
OTHER FEATURES
- Gotoh® machine heads
- Fishman® Fluence™ Voicing switch
- Luminlay side dots
- Hardshell case included

Features

Jumbo Stainless Steel frets with Prestige fret edge treatment

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.
The Prestige Fret Edge Treatment guarantees effortlessly fast playing.
