PFT2
SPEC
-
SPECS
-
body shapeMini Dreadnought body
-
topSpruce top
-
back & sidesSapele back & Sapele sides
-
neckPFTOkoume neck
-
fretboardPurpleheart fretboard
-
bridgePurpleheart bridge
-
inlayWhite dot inlay
-
soundhole rosetteBlack & White multi
-
tuning machineChrome Open Gear tuners
-
number of frets20
-
saddle materialBone
-
bridge pinsIbanez Advantage™
-
stringsD'Addario® J66
-
string gauge.010/.014/.022/.032
-
string space11mm
-
factory tuning1A,2D,3G,4C
-
-
NECK DIMENSIONS
-
-
Scale :580mm/22.8"
-
a : Width30mm at NUT
-
b : Width36mm at 14F
-
c : Thickness22mm at 1F
-
d : Thickness23mm at 7F
-
Radius :400mmR
-
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
BODY DIMENSIONS
-
-
a : Length15 5/8"
-
b : Width12 5/8"
-
c : Max Depth3 3/4"
-
-
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body
-
-
OTHER FEATURES
-
Recommended Bag
-
Features

Sapele back and sides
Sapele back and sides offer a full-bodied and warm mid-range and a bright tone.

Okoume neck
The Okoume neck provides greater playing comfort.

Purpleheart fretboard
The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.

Purpleheart bridge
The Purpleheart bridge transfers string vibration directly to the body, delivering a natural and warm tone.

Spruce top
Spruce remains the most popular wood for acoustic guitar tops, mainly due to its pristine tonal clarity.

Ibanez Advantage™ bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
