GRG121SP-BMC
  • BMC : Blue Metal Chameleon
  • COLOR VARIATION:
SHARE:
RG

SPEC

  • SPECS

    • neck type
      GRGRoasted Maple neck
    • top/back/body
      Poplar body
    • fretboard
      Jatoba fretboardWhite dot inlay
    • fret
      Medium frets
    • number of frets
      24
    • bridge
      F106 bridge
    • string space
      10.5mm
    • neck pickup
      Classic Elite (H) neck pickupPassive/Ceramic
    • bridge pickup
      Classic Elite (H) bridge pickupPassive/Ceramic
    • factory tuning
      1E,2B,3G,4D,5A,6E
    • string gauge
      .009/.011/.016/.024/.032/.042
    • hardware color
      Chrome
  • NECK DIMENSIONS

      • Scale :
        648mm/25.5"
      • a : Width
        43mm at NUT
      • b : Width
        58mm at 24F
      • c : Thickness
        19.5mm at 1F
      • d : Thickness
        21.5mm at 12F
      • Radius :
        400mmR
    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the first fret
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the twelfth fret
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    GRG121SP's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, bridge side of the neck pickup is selected. When the switch is in center position, both neck and bridge pickup s are selected. When the switch is in between center and bridge position, the bridge side of the neck pickup and the bridge side of the bridge pickup are selected. When the switch is in bridge position, bridge pickup is selected.

  • CONTROLS

    GRG121SP's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

  • OTHER FEATURES

Features

Classic Elite pickups

Classic Elite pickups

Classic Elite pickups offer rich, nuanced tone with fat low-end.

Mono-unit output jack

Mono-unit output jack

The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.

F106 bridge

F106 bridge

The F106 bridge enriches sustain. String height adjustment can be done easily and independently.

Jatoba Fretboard

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
