GA34STCE

PHOTOS
SPEC
FEATURES
SUPPORT

NT : Natural High Gloss

COLOR VARIATION：

CLASSICAL

SPEC

SPECS
- body shape

  Thinline Cutaway Classical body
- top

  Solid Spruce top
- back & sides

  Ovangkol back & Ovangkol sides
- neck

  GAOkoume neck
- fretboard

  Purpleheart fretboard
- bridge

  Purpleheart bridge
- soundhole rosette

  Classical Mosaic Design
- tuning machine

  Gold Classical tuners
- number of frets

  21
- strings

  Ibanez ICLS6NT
- string gauge

  .0280/.0322/.0403/.029/.035/.043
- string space

  11.6mm
- factory tuning

  1E,2B,3G,4D,5A,6E
- pickup

  Ibanez Undersaddle pickup
- preamp

  Ibanez AEQ210T preamp w/Onboard tuner
- output jack

  Balanced XLR & 1/4" outputs
NECK DIMENSIONS
- - Scale :

    650mm/25.6"
  - a : Width

    46mm at NUT
  - b : Width

    58mm at 14F
  - c : Thickness

    21mm at 1F
  - d : Thickness

    23mm at 7F
  - Radius :

    Flat
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
BODY DIMENSIONS
- - a : Length

    19 3/8"
  - b : Width

    14 3/4"
  - c : Max Depth

    2 7/8"
- DESCRIPTION

  Guitar Body Diagram
  A: Length of the body
  B: Maximum width of the body
  C: Maximum depth of the body
PREAMP

DESCRIPTION

The neck side of the preamp is the top of the control panel. The controls from left to right are the volume knob, tuner button, treble knob, phase button, and bass knob.
OTHER FEATURES
- Recommended Case

  AEG10C
