EH10
SPEC
-
SPECS
-
neck typeAZ Oval C Roasted Maple neck
-
top/back/bodyWalnut topNyatoh body
-
fretboardJatoba fretboardOff-set white block inlay
-
fretJumbo Stainless Steel frets
-
number of frets24
-
bridgeGotoh® T1502 tremolo bridge
-
string space10.5mm
-
neck pickupSeymour Duncan® Alnico II Pro™ (S) neck pickup
-
bridge pickupSeymour Duncan® Hyperion™ (H) bridge pickupPassive/Alnico
-
factory tuning1E,2B,3G,4D,5A,6E
-
stringsD'Addario® EXL110
-
string gauge.010/.013/.017/.026/.036/.046
-
nutGraph Tech®
-
hardware colorChrome
-
-
NECK DIMENSIONS
-
-
Scale :648mm/25.5"
-
a : Width42mm at NUT
-
b : Width57mm at 24F
-
c : Thickness20.5mm at 1F
-
d : Thickness22.5mm at 12F
-
Radius :305mmR
-
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When coil tap switch is in neck position, coil tap is on. When the coil tap switch is in bridge position, coil tap is off. When the coil tap is off and the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in center position, neck and bridge pickups are selected. When the switch is in bridge position, bridge pickup is selected. When the coil tap is on and the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in center position, center pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the neck side of the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is one knob and one switch along the located along the lower edge of the body. Closest to the knee cutout, there is a three-way pickup selector switch. Closest to the end of the body is the tone knob. The volume knob is located right above the three-way pickup selector switch. Between the volume and tone knobs is a coil tap switch. When the switch is in the neck position, the coil tap is on. When the switch is in bridge position, the coil tap is off.
-
OTHER FEATURES
-
Recommended Case
-
Gotoh® MG-T locking machine heads
-
Luminescent side dot inlay
-
Gig bag included
-
Features
Jatoba fretboard w/Off-set white block inlay
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
Roasted Maple neck
Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.
Super All Access Neck Joint
The Super All Access Neck Joint offers superior playability with its 8mm concave curve from the body top to the spherical surface of the joint area. By maximizing the joint area between the body and the neck, sustain and resonance are increased as well.
Seymour Duncan® Alnico II Pro™ Neck Pickup/Seymour Duncan® Hyperion™ Bridge Pickup
Combination of Seymour Duncan® Alnico II Pro™ neck pickup and Hyperion™ bridge pickup provides a vintage sound and vibe along with a clear picking attack.
Coil Tap Switch
The Coil Tap Switch equipped on the neck pickup greatly assist to create variety of sound with 3way lever switch.
Gotoh® T1502 tremolo bridge
T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings. Its snap-in construction makes it easy to load a tremolo arm.
Gotoh® MG-T locking machine heads
The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
Luminescent side dot inlays
The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
Graph Tech® TUSQ XL nut/Stainless Frets
The super smooth Graph Tech® nut increases tuning stability, sustain and clarity of sound. Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.
