BTB625EX
- BKF : Black Flat
- COLOR VARIATION：
SPEC
-
SPECS
-
neck typeBTB55pc Maple/Walnut w/Graphite reinforcement rodsNeck-through
-
top/back/bodyOkoume body
-
fretboardEbonol fretboard
-
fretMedium Stainless Steel frets
-
number of frets24 (+ zero fret)
-
bridgeMR5 bridge
-
string space19mm
-
neck pickupBartolini® BH2 neck pickupPassive
-
bridge pickupBartolini® BH2 bridge pickupPassive
-
equalizerIbanez Custom Electronics 3-band EQ w/ 3-way Mid frequency switch
-
factory tuning1G,2D,3A,4E,5B
-
stringsD'Addario® NYXL45130SL
-
string gauge.045/.065/.080/.100/.130
-
hardware colorBlack
-
-
NECK DIMENSIONS
-
-
Scale :889mm/35"
-
a : Width47mm at NUT
-
b : Width76mm at 24F
-
c : Thickness20mm at 1F
-
d : Thickness22mm at 12F
-
Radius :400mmR
-
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
CONTROLS
DESCRIPTION
-
FREQUENCY RESPONSE
DESCRIPTION
The bass boost/cut frequency curve has a peak at 20 Hz, the variable width becomes smaller toward the high range, and the variable width becomes zero at about 1000 Hz. The variable range of the peak frequency is approximately ±15 dB. The treble boost/cut frequency curve draws a mountain-shaped curve with a peak at around 10,000 Hz and zero variable range around 100 Hz. The variable range of the peak frequency is approximately ±15 dB. The mid-boost/cut frequency curve creates a bell-shaped curve that peaks at a specific frequency, and the variable range becomes zero near 20 Hz and around 10,000 Hz. The frequency peak can be switched to 700, 450 and 250 Hz. The variable range of the peak frequency is approximately ±15 dB.
-
OTHER FEATURES
- Recommended Case
-
MRB350C
Features
5pc Maple/Walnut neck with Graphite reinforcement rods
The 5pc Maple/Walnut neck provides tonal clarity and superior attack.The Graphite reinforcement rods provides massive sustain and excellent stability.
Ebonol fretboard
Ebonol is a synthetic material which is made from layers of black paper and phenolic resin. An Ebonol fretboard provides tight and bright sound.
Okoume body
The Okoume body provides a bright and solid sound.
Bartolini® BH2 pickups
The Bartolini® BH2 pickups provide a tight bottom-end, punchy mid-range, and smooth response. The dual-coil style configuration maximizes articulation and a long blade pole piece widens the magnetic field, providing balanced string-to-string pickup response.
Ibanez Custom Electronics 3-band EQ
The Ibanez Custom Electronics 3-band EQ is our latest refinement on the concept of simple, straightforward, no-nonsense EQ control. The Boost and Cut for the Mid Control are each centered on slightly different frequencies, an innovation that delivers a preset range of the most favorable bass tones.
MR5 bridge
The Mono-Rail V is the ultimate bridge for bass string isolation. Each bridge is independently and securely locked down to the body for maximum vibration transfer without interference.
3-way Mid frequency switch
The 3-way Mid frequency switch allow players to change the mid-tone between 250, 450, and 700 Hz.
