TF : Tobacco Flat
TKF : Transparent Black Flat

COLOR VARIATION：

SPEC

SPECS
- neck type

  AS ArtcoreNyatohset-in neck
- top/back/side

  Linden top Linden backLinden sides
- fretboard

  Bound Rosewood fretboardWhite dot inlay
- fret

  Medium frets
- number of frets

  22
- bridge

  Gibraltar Performer bridge
- string space

  10.5mm
- tailpiece

  Quik Change III tailpiece
- neck pickup

  Infinity R (H) neck pickupPassive/Ceramic
- bridge pickup

  Infinity R (H) bridge pickupPassive/Ceramic
- factory tuning

  1E,2B,3G,4D,5A,6E
- string gauge

  .010/.013/.017/.030/.042/.052
- hardware color

  Chrome
NECK DIMENSIONS
- - Scale :

    628mm
  - a : Width

    43mm at NUT
  - b : Width

    57mm at 22F
  - c : Thickness

    21mm at 1F
  - d : Thickness

    24mm at 9F
  - Radius :

    305mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
BODY DIMENSIONS
- - a : Length

    19 1/4"
  - b : Width

    15 3/4"
  - c : Max Depth

    2 5/8"
- DESCRIPTION

  Guitar Body Diagram
  A: Length of the body
  B: Maximum width of the body
  C: Maximum depth of the body
SWITCHING SYSTEM

DESCRIPTION

When the pickup selector switch is in the neck position, the neck pickup is active. When the switch is in the center position, both the neck and bridge pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.
CONTROLS

DESCRIPTION

There are two knobs and one switch on this guitar. The tone knob is located near the edge of the body, and the knob closest to the neck is the volume knob. The switch located between these knobs is a three -way pickup selector switch.
OTHER FEATURES
- Recommended Case

  MS100C
