AGB200

PHOTOS
SPEC
FEATURES
SUPPORT

BKF : Black Flat
NT : Natural

COLOR VARIATION：

AGB

SPEC

SPECS
- neck type

  AGB43pc Nyatoh/MapleSet-in
- top/back/body

  Linden topLinden sidesLinden back
- fretboard

  Bound Rosewood fretboardWhite dot inlay
- fret

  Medium frets
- number of frets

  22
- bridge

  Gibraltar III Bass bridge
- string space

  19mm
- tailpiece

  Quik Change III Bass tailpiece
- neck pickup

  Classic Elite Bass neck pickupPassive
- bridge pickup

  Classic Elite Bass bridge pickupPassive
- factory tuning

  1G,2D,3A,4E
- string gauge

  .050/.070/.085/.105
- hardware color

  Chrome
NECK DIMENSIONS
- - Scale :

    770mm/30.3"
  - a : Width

    42mm at NUT
  - b : Width

    61mm at 22F
  - c : Thickness

    21.5mm at 1F
  - d : Thickness

    24mm at 9F
  - Radius :

    400mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
CONTROLS

DESCRIPTION

With the bass held in the playing position, the pickup selector switch is the control closest to the lower edge of the body. Just above the selector switch, there are two knobs arranged diagonally. The knob closest to the input jack is the tone knob. The knob closest to the neck is the volume knob.
OTHER FEATURES
- Recommended Case
- AGB100C

Features

3pc Nyatoh/Maple neck

3pc Nyatoh/Maple neck

The 3pc Nyatoh/Maple Neck provides a rich mid-low end and great resonance.

Rosewood fretboard

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Linden top / Linden back and sides

Linden top / Linden back and sides

Linden delivers a natural and flat, yet accurate, tone.

Gibraltar III Bass bridge

Gibraltar III Bass bridge

The Gibraltar III bridge provides a rich sustain.

Quik Change III Bass tailpiece

Quik Change III Bass tailpiece

The Quick Change III Bass tailpiece offers easy string changes.

Classic Elite Bass Pickup

Classic Elite Bass Pickup

Classic Elite Bass Pickups deliver classic tone, punch and extra output.
