AC340CE

PHOTOS
SPEC
FEATURES
SUPPORT

OPN : Open Pore Natural

COLOR VARIATION：

ARTWOOD

SPEC

SPECS
- body shape

  Cutaway Grand Concert body
- top

  Solid Okoume top
- back & sides

  Okoume back & Okoume sides
- neck

  ACNyatoh neck
- fretboard

  Ovangkol fretboard
- bridge

  Thermo Aged™ Ovangkol bridge
- inlay

  White dot inlay
- soundhole rosette

  Black & White multi
- tuning machine

  Chrome Die-cast tuners (18:1 gear ratio)
- nut material

  Bone
- number of frets

  20
- saddle material

  Compensated Bone
- bridge pins

  Ibanez Advantage™
- strings

  D'Addario® XTAPB1253
- string gauge

  .012/.016/.024/.032/.042/.053
- string space

  11mm
- factory tuning

  1E,2B,3G,4D,5A,6E
- pickup

  Fishman® S-Core
- preamp

  Ibanez AEQ-SP2 preamp w/Onboard tuner
- output jack

  Balanced XLR & 1/4" outputs
- battery

  9V x1
NECK DIMENSIONS
- - Scale :

    634mm/25"
  - a : Width

    45mm at NUT
  - b : Width

    56mm at 14F
  - c : Thickness

    21mm at 1F
  - d : Thickness

    22mm at 7F
  - Radius :

    400mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the fret position specified by the neck dimension
  c: Thickness of the neck at the first fret
  d: Thickness of the neck at the fret position specified by the neck dimension
  Radius: Radius of the fingerboard
BODY DIMENSIONS
- - a : Length

    19 3/8"
  - b : Width

    15 1/4"
  - c : Max Depth

    4 1/4"
- DESCRIPTION

  Guitar Body Diagram
  A: Length of the body
  B: Maximum width of the body
  C: Maximum depth of the body
PREAMP

DESCRIPTION

The neck side of the preamp is the top of the control panel. There is one button and three knobs along the top of the control panel. The button furthest to the left is the tuner on/off switch. To the right of that are the bass, treble, and volume knobs.
OTHER FEATURES
- Recommended Case

  AC100C
- Thermo Aged™ Maple bridge plate

Features

Nyatoh neck

The Nyatoh neck provides a rich mid-low end.

Solid Okoume top

Solid Okoume top offers a full-bodied and warm mid-range and a bright tone.

Thermo Aged™ Ovangkol bridge

Thermo Aged, a special drying process, makes the Ovangkol bridge light and hard and provides stability and better resonance with enhanced lows and low-mids.

Ibanez AEQ-SP2 preamp w/Onboard tuner

The Ibanez AEQ-SP2 Preamp delivers excellent sonic reproduction and control of tonal characteristics and easy operation

Ovangkol fretboard

The Ovangkol fretboard provides greater playing comfort.

Okoume back and sides

The Okoume back and sides generate a woody, warm tone when the guitar is played softly or finger-picked and provide punchy high-mids with a clear projection when strummed.

Ibanez Advantage™ bridge pins

These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
