TMB425B
- BKF : Black Flat
- COLOR VARIATION：
SPEC
-
SPECS
- neck type
- TMB5Roasted Maple neck
- top/back/body
- Okoume body
- fretboard
- Ebonol fretboard
- fret
- Medium frets
- number of frets
- 20
- bridge
- B15W bridge
- string space
- 18mm
- neck pickup
- Dynamix P neck pickupPassive
- bridge pickup
- Dynamix J bridge pickupPassive
- equalizer
- Ibanez Custom Electronics 2-band EQ
- factory tuning
- 1G,2D,3A,4E,5B
- strings
- D'Addario® EXL165 + .130
- string gauge
- .045/.065/.085/.105/.130
- hardware color
- Black
-
NECK DIMENSIONS
-
- Scale :
- 864mm/34"
- a : Width
- 45mm at NUT
- b : Width
- 72mm at 20F
- c : Thickness
- 21.5mm at 1F
- d : Thickness
- 24.5mm at 12F
- Radius :
- 240mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimensiont
Radius: Radius of the fingerboard
-
-
CONTROLS
DESCRIPTION
There are two stacked knobs on this bass. The top knob of the stack closest to the end of the body is the treble boost/cut control, and the lower knob is the bass boost/cut control. The top knob of the stack closest to the neck is the volume control, and the lower knob is pickup balancer.
-
FREQUENCY RESPONSE
DESCRIPTION
The bass boost/cut frequency curve has a peak at 20 Hz and a variable width that decreases toward the high range, and a curve that the variable width becomes zero at approximately 1000 Hz. The variable range becomes slightly larger in the high range than around 1000 Hz, but it becomes zero again near 5000 Hz. The variable range of the peak frequency is approximately ±15 dB. The treble boost/cut frequency curve creates a bell-shaped curve with a peak around 10000 Hz and zero variable range around 100 Hz. The variable range of the peak frequency is approximately ±15 dB.
-
OTHER FEATURES
Features
Roasted Maple neck
The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.
Ebonol fretboard
Ebonol is a synthetic material which is made from layers of black paper and phenolic resin. An Ebonol fretboard provides tight and bright sound.
Okoume body
The Okoume body provides a bright and solid sound.
Dynamix PJ pickups
Dynamix PJ pickups deliver clarity and fullness.
Ibanez Custom Electronics 2-band EQ
The Ibanez Custom Electronics 2-band EQ offers a wide range of sounds.
B10 series bridge
The B10 bridge allows fully adjustable intonation and solid tuning stability.
