RG5120M-FCN
RG5120M-PRT
  • FCN : Frozen Ocean
  • PRT : Polar Lights
  • COLOR VARIATION:
RG

SPEC

  • SPECS

    • neck type
    • Super Wizard HP 5pc Maple/Wenge neck
    • top/back/body
    • Ash top (FCN finish only)African Mahogany body
    • fretboard
    • Bound Birdseye Maple fretboardOff-set Mother of Pearl dot inlay
    • fret
    • Jumbo Stainless Steel frets
    • number of frets
    • 24
    • bridge
    • Lo-Pro Edge tremolo bridge
    • string space
    • 10.8mm
    • neck pickup
    • Fishman® Fluence™ Modern Humbucker Ceramic (H) neck pickupActive/Ceramic
    • bridge pickup
    • Fishman® Fluence™ Modern Humbucker Ceramic (H) bridge pickupActive/Ceramic
    • factory tuning
    • 1E,2B,3G,4D,5A,6E
    • strings
    • D'Addario® EXL120
    • string gauge
    • .009/.011/.016/.024/.032/.042
    • hardware color
    • Cosmo black
  • NECK DIMENSIONS

      • Scale :
      • 648mm/25.5"
      • a : Width
      • 43mm at NUT
      • b : Width
      • 58mm at 24F
      • c : Thickness
      • 17mm at 1F
      • d : Thickness
      • 19mm at 12F
      • Radius :
      • 430mmR
    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the fret position specified by the neck dimension
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the fret position specified by the neck dimension
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    RG5120M's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.

  • CONTROLS

    RG5120M's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the knee cutout is a three-way pickup selector switch. Closer to the end of the body is the tone knob. The volume knob is located right above the three-way pickup selector switch. Between the volume and tone knobs is a Fishman Fluence voicing switch. When the switch is in the neck position, the pickup is set to voicing 2. When the switch is in the bridge position, the pickup is set to voicing 1.

  • OTHER FEATURES

    • Fishman® Fluence Voicing switch
    • Gotoh® machine heads
    • Luminlay side dots
    • Hardshell case included

Features

Super Wizard HP 5pc Maple/Wenge neck

Super Wizard HP 5pc Maple/Wenge neck

Super Wizard 5pc Maple/Wenge neck provides extra-smooth playing.

Birdseye Maple Fretboard

Birdseye Maple Fretboard

Birdseye Maple has a unique wood grain and features a well-balanced tonal character from low to high end.

Lo-Pro Edge tremolo bridge

Lo-Pro Edge tremolo bridge

The legendary Lo-Pro Edge bridge offers maximum playing comfort with its streamlined profile and recessed fine tuners. Locking studs contribute to tuning stability.

Fishman Fluence Modern Humbucker pickups

Fishman® Fluence Modern Humbucker pickups

The Fishman Fluence Modern Humbucker pickups provide an aggressive tone and a powerful attack without excess noise.

Luminlay side dot inlays

Luminlay side dot inlays

The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

Gotoh® machine heads

Gotoh® machine heads

Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.

Hardshell case included

Hardshell case included
