PGM50
SPEC
-
SPECS
- neck type
- PGM5pc Maple/Walnut
- top/back/body
- American Basswood body
- fretboard
- Rosewood fretboardWhite dot inlay
- fret
- Medium fretsPremium fret edge treatment
- number of frets
- 22
- bridge
- F106 bridge
- string space
- 10.5mm
- neck pickup
- DiMarzio® Air Classic™ (H) neck pickupAlnico/Passive
- middle pickup
- DiMarzio® PGM™ (S) middle pickupAlnico/Passive
- bridge pickup
- DiMarzio® Air Classic™ (H) bridge pickupAlnico/Passive
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- hardware color
- Gold
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 57mm at 22F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 22mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck humbucker is selected. When the switch is between neck and center position, the bridge side of the neck humbucker and the center pickup are selected. When the switch is in center position, the center pickup is selected. When the switch is between the center and bridge position, center pickup and the neck side of the bridge humbucker are selected. When the switch is in bridge position, the bridge humbucker is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is a five-way pickup selector switch close to the edge of the body. The volume knob is located near the end of the body.
-
OTHER FEATURES
Features
5pc Maple/Walnut neck
The 5pc Maple/Walnut neck provides tonal clarity and superior attack.
Rosewood fretboard
Rosewood fretboard provides a well-balanced solid tone with a focused mid range.
Medium frets with Premium fret edge treatment
Medium sized frets enhances the accuracy to your notes.
The Premium Fret Edge Treatment offers a super smooth, comfortable performance.
American Basswood body
The American Basswood body delivers a natural and flat tone.
DiMarzio® Air Classic™ (H) / DiMarzio® PGM™ (S) / DiMarzio® Air Classic™ (H) pickups
DiMarzio® Air Classic™ pickup combining vintage voicing with modern technology delivers an incredible touch-sensitive sound. DiMarzio® PGM single-coil middle pickup provides a perfect mix of vintage and modern sounds.
Gotoh® MG-T locking machine heads
The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.
F106 bridge
The F106 bridge enriches sustain. String height adjustment can be done easily and independently.
