JS240PS
SPEC
-
SPECS
- neck type
- JS3pc Maple/Bubinga neck w/KTS™ TITANIUM rods
- top/back/body
- American Basswood body
- fretboard
- Rosewood fretboardWhite dot inlay
- fret
- Medium fretsPremium fret edge treatment
- number of frets
- 24
- bridge
- Edge bridge
- string space
- 10.8mm
- neck pickup
- SUSTAINIAC® Driver (S) neck pickup
- bridge pickup
- DiMarzio® The Satchur8™ (H) bridge pickupPassive/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 42mm at NUT
- b : Width
- 56mm at 24F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 22.3mm at 12F
- Radius :
- 250mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the tone knob is pulled up, the Susutainiac is on. When the tone knob is down, the Susutainiac is off. When the Sustainiac is off and the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in center position, both the neck pickup and the bridge pickups are selected. When the switch is in bridge position, the bridge pickup is selected. When the Sustainiac is activated, whichever position the switch is in, the neck and bridge pickups are selected and the Sustainiac is affecting the sound of the neck pickup.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there are two switches along the lower edge of the body. The switch closest to the knee cutout is the three-way pickup selector switch, and the switch closest to the end of the body is the three way sustainicac switch. When the sustainiac switch is in neck position, the sustainiac is in normal mode, when the switch is in center position, the susutainiac is in mix mode, and when the switch is in bridge position, the sustainiac is in harmonic mode. There are two knobs towards the center of the guitar. The knob closest to the end of the body is the tone knob, and the knob closer to the neck is the volume knob. The tone knob also functions as a sustainiac on/off switch, while the volume knob also works as a high pass filter switch. They are both engaged by pulling up on the knob.
-
OTHER FEATURES
- Recommended Case
-
MR500C
- Gig bag included
- High-Pass filter on volume control
- Sustainiac switch on tone control (push/pull)
- 3-way mini switch for Sustainiac
Features
3pc Maple/Bubinga neck with KTS™ TITANIUM rods
The 3pc Maple/Bubinga neck w/ KTS™ TITANIUM rods provides absolute rock solid stability and extra-smooth playing.
Rosewood fretboard
Rosewood provides a well-balanced solid tone with a focused mid range.
High-pass filter on volume control (push/pull)
A high pass filter on the volume pot maintains highs at low volumes.
Edge tremolo
The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.
SUSTAINIAC® Driver / DiMarzio® Satchur8™ pickups
The SUSTAINIAC® Driver in the neck position is wired to "Stealth PRO" preamp specially customized for Joe. It allows endless sustain and expands the range of expression dramatically with a 3-way Sustainiac mode selector. DiMarzio® Satchur8™ pickup fully supports Joe's versatile playing style and massive sound.
Premium Fret Edge Treatment
Premium Fret Edge Treatment offer super smooth,comfortable performance.
