ICHI00-VWH
  • VWH : Vintage White
  • COLOR VARIATION:
ICHI

SPEC

  • SPECS

    • neck type
    • Wizard CRoasted Maple neck
    • top/back/body
    • Nyatoh body
    • fretboard
    • Rosewood fretboardWhite dot inlay
    • fret
    • Medium frets
    • number of frets
    • 22
    • bridge
    • T106 bridge
    • string space
    • 10.5mm
    • neck pickup
    • ICHI-S (S) neck pickupPassive/Ceramic
    • middle pickup
    • ICHI-S (S) middle pickupPassive/Ceramic
    • bridge pickup
    • ICHI-S (S) bridge pickupPassive/Ceramic
    • factory tuning
    • 1E,2B,3G,4D,5A,6E
    • strings
    • D'Addario® EXL120
    • string gauge
    • .009/.011/.016/.024/.032/.042
    • hardware color
    • Chrome
  • NECK DIMENSIONS

      • Scale :
      • 648mm/25.5"
      • a : Width
      • 41mm at NUT
      • b : Width
      • 57mm at 22F
      • c : Thickness
      • 21mm at 1F
      • d : Thickness
      • 22mm at 12F
      • Radius :
      • 305mmR
    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the fret position specified by the neck dimension
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the fret position specified by the neck dimension
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    ICHI00's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in neck position, the neck pickup is active. When the switch is between neck and center position, the neck and center pickups are active. When the switch is in center position, the center pickup is active. When the switch is between the center and bridge position, the center pickup and bridge pickup are active. When the switch is in bridge position, the bridge pickup is active.

  • CONTROLS

    ICHI00's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

  • OTHER FEATURES

    • Gotoh® MG-T locking machine heads
    • Luminescent side dot inlay

Features

Wizard C Roasted Maple neck

Wizard C Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes. To meet the demand of various playing styles, this Wizard C neck has a very neutral shape – it’s not too thick, too thin, or too flat.

Rosewood fretboard

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Nyatoh body

Nyatoh body

Nyatoh used as the body wood provides a rich mid-low end.

ICHI-S pickups

ICHI-S pickups

Ichika and Ibanez jointly developed these 'ICHI-S' pickups to perfectly express the 'Ichika sound'.

Gotoh® MG-T locking machine heads

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

T106 tremolo

T106 tremolo

The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.
