ATZ300
SPEC
-
SPECS
- neck type
- ATS-TECH WOOD Roasted Maple neck
- top/back/body
- African Mahogany body
- fretboard
- Rosewood fretboardATZ special inlay
- fret
- Jumbo fretsPrestige fret edge treatment
- number of frets
- 22
- bridge
- Wilkinson®-Gotoh® VSVG bridge
- string space
- 10.8mm
- neck pickup
- DiMarzio® The Cruiser® (H) neck pickupPassive/Ceramic
- middle pickup
- DiMarzio® The Cruiser® (H) middle pickupPassive/Ceramic
- bridge pickup
- DiMarzio® AT-1™ (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- nut
- Bone nut
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 40mm at NUT
- b : Width
- 55mm at 21F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 23mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, the neck and center pickups are selected. When the switch is in center position, the center pickup is selected. When the switch is between center and bridge position, the center pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is a five-way pickup selector switch close to the lower edge of the body. Additionally, there are three knobs arranged diagonally near the end of the body. From the end of the body towards the neck they are; bridge tone, neck and middle tone, and the volume knob.
-
OTHER FEATURES
- Recommended Bag
-
IGB724-BK
- Hardshell case included
- Gotoh® Magnum Lock machine heads w/H.A.P.
- Luminlay side dots
- Oil-impregnated Bone nut
- Smooth taper volume filter
Features

S-TECH WOOD Roasted Maple neck
The S-TECH special roasted treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes. The neck is sealed with an oil finish which helps make it feel similar to a well-played guitar neck.

Rosewood fretboard
Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Jumbo frets with Prestige fret edge treatment
The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes. Prestige Fret Edge Treatment guarantees effortlessly fast playing.

African Mahogany body
The African Mahogany body delivers a rich mid-low end.

DiMarzio® The Cruiser® /AT-1™ pickups
A DiMarzio® The Cruiser® in the neck position delivers single-coil tone, open vocal-sounding mids and a bit of added strength to the bass. A DiMarzio®AT-1™ in the bridge position gives excellent warmth and clarity, which balances well with the neck pickup.

Gotoh® Magnum Lock w/H.A.P. machine heads
GOTOH® MAGNUM LOCK® machine heads have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.

Wilkinson®-Gotoh® VSVG tremolo
The Wilkinson®-Gotoh® VSVG tremolo unit features smooth arm action and the unique design of its elongated baseplate screw holes help promote accurate pitch return by eliminating binding. The VSVG's locking bent-steel saddles provide a vintage tone and feel.

Oil-impregnated Bone nut
The Oil-impregnated bone nut provides superior tuning stability and warm rich resonance. Stainless steel frets boast excellent corrosion resistance.

Smooth taper volume filter
A smooth taper volume filter maintains the guitar's high frequencies at low volumes and provides more uniform tone from 1 to 10.

Luminlay side dot inlays
The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
