RGMS7PB
- CBS : Cosmic Blue Starburst
- COLOR VARIATION：
SPEC
-
SPECS
- neck type
- Wizard III-7 for Multi Scale5pc Maple/Walnut neck
- top/back/body
- Poplar Burl topNyatoh body
- fretboard
- Jatoba fretboardWhite Step off-set dot inlay
- fret
- Jumbo frets
- number of frets
- 24
- bridge
- Mono-rail bridge
- string space
- 10.8mm
- neck pickup
- Array 7 MS (H) neck pickupPassive/Ceramic
- bridge pickup
- Array 7 MS (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E,7B
- strings
- D'Addario® EXL120+.059
- string gauge
- .009/.011/.016/.024/.032/.042/.059
- hardware color
- Cosmo Black
-
NECK DIMENSIONS
-
- Scale :
- 686mm/27.0" - 648mm/25.5"
- a : Width
- 48mm at NUT
- b : Width
- 68mm at 24F
- c : Thickness
- 19mm at 1F
- d : Thickness
- 21mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
-
OTHER FEATURES
Features
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
Mono-rail bridge
Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings
Poplar Burl top / Nyatoh body
The Poplar Burl top features an exotic wood grain and the Nyatoh body provides a rich mid-low end.
Array-7 MS pickups
Ibanez Array pickups deliver a super tight tone with low noise that handle down-tuning perfectly.
Wizard III 5pc Maple/Walnut neck
Ibanez's thin, flat and fast Wizard neck is strong and sturdy and offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
