PS10
SPEC
-
SPECS
- neck type
- PS3pc MapleSet-in neck (smooth heel)
- top/back/body
- Maple topAfrican Mahogany body
- fretboard
- Bound Ebony fretboardAcrylic & Abalone block inlay
- fret
- Medium fretsPrestige fret edge treatment
- number of frets
- 22
- bridge
- Gotoh® GE103B-T bridge
- string space
- 10.4mm
- tailpiece
- Gotoh® GE101Z-T tailpiece
- neck pickup
- Seymour Duncan® '59 model™ (H) neck pickupPassive/Alnico
- bridge pickup
- Seymour Duncan® Custom 5™ (H) bridge pickupPassive/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Half-Bone/Half-Brass nut
- hardware color
- Chrome
-
NECK DIMENSIONS
-
- Scale :
- 628mm/24.7"
- a : Width
- 43mm at NUT
- b : Width
- 57mm at 22F
- c : Thickness
- 20.5mm at 1F
- d : Thickness
- 23.5mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in the neck position, the neck pickup is active. When the switch is in the center position, both the neck and bridge pickups are selected. When the switch is in the bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there are three knobs located along the lower edge of the body. From the end of the body towards the neck they are; tone, bridge volume, and neck volume knob. A three-way pickup selector switch is located towards the upper half of the guitar near the neck pickup.
-
OTHER FEATURES
Features
All Access Neck Joint
j.custom special neck joint offers superior playability at the high frets.
PS original tailpiece ornament
Seymour Duncan® pickups
The PS10 features Seymour Duncan® '59 model and Custom 5™ pickups which provide a balanced and warm tone.
Ebony fretboard
Ebony produces a tight low and mid range with an iconic attack on the high end. It also features a quick response and rich sustain.
Half-Bone/Half Brass Nut
The PS10 features a specially-designed half bone/half brass nut.
