PC12MH
- OPN : Open Pore Natural
- COLOR VARIATION：
COLOR VARIATION
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
SPEC
-
SPECS
- body shape
- Grand Concert body
- top
- Okoume top
- back & sides
- Okoume back & Okoume sides
- neck
- PCNyatoh neck
- fretboard
- Laurel fretboard
- bridge
- Laurel bridge
- inlay
- White dot inlay
- soundhole rosette
- Tortoiseshell
- tuning machine
- Chrome Die-cast tuners
- number of frets
- 20
- bridge pins
- Ibanez Advantage™
- strings
- Ibanez IACS6C
- string gauge
- .012/.016/.024/.032/.042/.053
- string space
- 11mm
- factory tuning
- 1E,2B,3G,4D,5A,6E
-
NECK DIMENSIONS
- Scale :
- 634mm/25"
- a : Width
- 42mm at NUT
- b : Width
- 54mm at 14F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 22.5mm at 7F
- Radius :
- 240mmR
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard -
BODY DIMENSIONS
- a : Length
- 19 3/8"
- b : Width
- 15 1/4"
- c : Max Depth
- 4 1/4"
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body -
OTHER FEATURES
- Recommended Bag
-
ICB540-BK
Features
Nyatoh neck
The Nyatoh neck provides a rich mid-low end.
Laurel fretboard
The Laurel fretboard provides a rich and warm tone.
Laurel bridge
The Laurel bridge transfers string vibration directly to the body, delivering a natural and warm tone.
Okoume back and sides
The Okoume back and sides generate a woody, warm tone when the guitar is played softly or finger-picked and provide punchy high-mids with a clear projection when strummed.
Ibanez Advantage™ bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
