JIVAX2
SPEC
-
SPECS
- neck type
- JIVA5pc Maple/Wenge neck
- top/back/body
- Quilted Maple topAfrican Mahogany body
- fretboard
- Bound Ebony fretboardBeaten Path inlay
- fret
- Jumbo fretsPrestige fret edge treatment
- number of frets
- 24
- bridge
- Edge-Zero w/ZPS3 bridge
- string space
- 10.8mm
- neck pickup
- DiMarzio® Pandemonium™ (H) neck pickupPassive/Ceramic
- middle pickup
- DiMarzio® True Velvet™ (S) middle pickupPassive/Alnico
- bridge pickup
- DiMarzio® Pandemonium™ (H) bridge pickupPassive/Ceramic
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- Cosmo black
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 17mm at 1F
- d : Thickness
- 19mm at 12F
- Radius :
- 430mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck humbucker is selected. When the switch is between neck and center position, the bridge side of the neck humbucker and the center pickup are selected. When the switch is in center position, the center pickup is selected. When the switch is between the center and bridge position, center pickup and the neck side of the bridge humbucker are selected. When the switch is in bridge position, the bridge humbucker is selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
-
OTHER FEATURES
Features
5pc Maple/Wenge neck
The 5pc Maple/Wenge Neck with excellent strength provides an enriched resonance.
Ebony fretboard
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
Quilted Maple top / African Mahogany body
The Quilted Maple top sonically enriches the response for picking. The African Mahogany body delivers a rich mid-low end.
DiMarzio® Pandemonium™ / DiMarzio® True Velvet™ pickups
DiMarzio® Pandemonium™ pickups have a modern take on a classic rock sound that Nita desires.
Gotoh® machine heads
Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.
Edge-Zero tremolo with Zero Point System
The Edge-Zero has a sharp knife-edge for extremely accurate tremolo playing. This tremolo also uses Ibanez innovations to keep string action constant and the bridge surface smooth. The specially-designed arm socket prevents unnecessary wobble while providing full control over the arm's torque.
In addtion, the zero point system offers much greater tuning stability.
Luminlay side dot inlays
The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
