EWP14WB
- OPN : Open Pore Natural
- COLOR VARIATION：
COLOR VARIATION
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
-
Enlarge image (opens in a modal window)
SPEC
-
SPECS
- body shape
- Cutaway Tenor Style EW body
- top
- Ovangkol top
- back & sides
- Ovangkol back & Ovangkol sides
- neck
- EWPOkoume neck
- fretboard
- Purpleheart fretboard
- bridge
- Purpleheart bridge
- inlay
- Maple dot inlay
- soundhole rosette
- Abalone rosette
- tuning machine
- Chrome Die-cast tuners
- number of frets
- 19
- bridge pins
- Ibanez Advantage™
- string gauge
- .010/.014/.023/.030/.039/.047
- string space
- 9.6mm
- factory tuning
- 1A,2E,3C,4G,5D,6A
-
NECK DIMENSIONS
- Scale :
- 432mm/17"
- a : Width
- 42mm at NUT
- b : Width
- 50mm at 14F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 21mm at 7F
- Radius :
- 400mmR
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard -
BODY DIMENSIONS
- a : Length
- 12 1/8"
- b : Width
- 9 3/8"
- c : Max Depth
- 2 7/8"
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body -
OTHER FEATURES
- Gig bag included
Features
Okoume neck
The Okoume neck provides greater playing comfort.
Purpleheart bridge
The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.
Purpleheart bridge
The Purpleheart bridge transfers string vibration directly to the body, delivering a natural and warm tone.
Ibanez Advantage™ bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
