EWP14WB
- OPN : Open Pore Natural
- COLOR VARIATION：
SPEC
-
SPECS
- body shape
- Cutaway Tenor Style EW body
- top
- Ovangkol top
- back & sides
- Ovangkol back & Ovangkol sides
- neck
- EWPOkoume neck
- fretboard
- Purpleheart fretboard
- bridge
- Purpleheart bridge
- inlay
- Maple dot inlay
- soundhole rosette
- Abalone
- tuning machine
- Chrome Die-cast tuners
- number of frets
- 19
- bridge pins
- Ibanez Advantage™
- string gauge
- .010/.014/.023/.030/.039/.047
- string space
- 9.6mm
- factory tuning
- 1A,2E,3C,4G,5D,6A
-
NECK DIMENSIONS
-
- Scale :
- 432mm/17"
- a : Width
- 42mm at NUT
- b : Width
- 50mm at 14F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 21mm at 7F
- Radius :
- 400mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
BODY DIMENSIONS
-
- a : Length
- 12 1/8"
- b : Width
- 9 3/8"
- c : Max Depth
- 2 7/8"
-
DESCRIPTION
Guitar Body Diagram
A: Length of the body
B: Maximum width of the body
C: Maximum depth of the body
-
-
OTHER FEATURES
- Gig bag included
Features
Okoume neck
The Okoume neck provides greater playing comfort.
Purpleheart fretboard & bridge
Purpleheart produces a rich mid range with a crisp high end.
Ibanez Advantage™ bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
