SML721
SPEC
-
SPEC
- neck type
- Wizard5拼枫木/胡桃木琴颈
- top/back/body
- 椿茶木琴体
- fretboard
- 玫瑰木指板白色偏置圆点镶嵌
- fret
- 大号不锈钢品丝
- number of frets
- 24
- bridge
- Mono-rail琴桥
- string space
- 10.8mm
- neck pickup
- Q58 (双) 琴颈拾音器被动/陶瓷
- bridge pickup
- Q58 (双) 琴桥拾音器被动/陶瓷
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- hardware color
- 金色硬件
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5" - 635mm/25.0"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 18mm at 1F
- d : Thickness
- 20mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
吉他颈部图
a: 上琴枕部位的指板宽度
b: 指定品位的指板宽度
c: 第一品位的琴颈厚度
d: 指定品位的琴颈厚度
Radius: 指板曲面的半径
-
-
SWITCHING SYSTEM
DESCRIPTION
When the alter switch is in neck position, power tap mode is on. When the alter switch is in bridge position, power tap mode is off. When power tap mode is off and the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, the neck side of the neck pickup and the bridge side of the bridge pickup are selected. When the switch is in bridge position, bridge pickup is selected. When power tap mode is on and the pickup selector switch is in neck position, the neck pickup is selected and in power tap mode. When the switch is in between neck and center position, bridge side of the neck pickup is selected. When the switch is in the center position, both neck and bridge pickups are selected and are both in power tap mode. When the switch is in between center and bridge position, the bridge side of the bridge pickup is selected. When the switch is in bridge position, bridge pickup is selected and is in power tap mode.
-
CONTROLS
DESCRIPTION
将吉他保持在弹奏位置时,在琴体下部控制旋钮附近有一个五段拾音器选择开关。在此上方,琴桥附近有两个旋钮。最靠近琴体末端的旋钮是音色旋钮(仅适用于琴颈拾音器),而最靠近琴颈的旋钮是音量旋钮。在音量和音色旋钮之间是Alter开关。Alter开关在向上位置打开,在向下位置关闭。
-
OTHERS
Features

Wizard 5拼 枫木/胡桃木琴颈
Ibanez 纤薄、平坦且顺滑的 Wizard 琴颈结实而坚固,为追求极致的演奏者提供无限的可玩性。

玫瑰木指板
玫瑰木指板提供均衡的纯音和集中的中频。

椿茶木琴体
用作琴体木材的椿茶木提供了丰富的中低音。

Q58 H-H 拾音器
Q58 拾音器专为无头吉他而设计。 它们提供清晰定义的声音,促进所有频率的出色音调平衡。 低音有力而不浑浊,高音明亮清晰,但从不刺耳。 因此,和弦结构中的每个音符都清晰可辨。 这些拾音器具有音调平衡和极低的噪音性能,非常适合数字和模拟效果器。

Mono-rail琴桥
创新的 Ibanez Mono-Rail 琴桥专为稳定性和延音而设计,可最大限度地减少琴弦之间的串扰

dyna-MIX10 开关系统 带/切换开关
dyna-MIX 10 提供十种声音变化,并且可以使用迷你开关轻松地在双线圈模式和单线圈模式之间切换。 power Tap 模式提供逼真的单线圈声音,尽管它由两个双线圈拾音器组成的布局。

夜光侧圆点镶嵌
夜光侧圆点标记使演奏者在黑暗的舞台上表演时很容易看到指板位置。

Gotoh® MG-T 带锁弦钮
Gotoh®MG-T带锁弦钮实现了令人难以置信的调音稳定性,减少了换弦时间。
