RGR6BSP
SPEC
-
SPEC
- neck type
- Wizard III5拼枫木/胡桃木琴颈
- top/back/body
- 椿茶木琴体
- fretboard
- 乌木指板
- fret
- 大号品丝
- number of frets
- 24
- bridge
- Edge-Zero II 颤音琴桥
- string space
- 10.8mm
- neck pickup
- Fishman® Fluence™ Modern Humbucker Alnico (双) 琴颈拾音器主动/Alnico
- bridge pickup
- Fishman® Fluence™ Modern Humbucker Ceramic (双) 琴桥拾音器主动/陶瓷
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- 黑色和金属蓝硬件
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 19mm at 1F
- d : Thickness
- 21mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
吉他颈部图
a: 上琴枕部位的指板宽度
b: 指定品位的指板宽度
c: 第一品位的琴颈厚度
d: 指定品位的琴颈厚度
Radius: 指板曲面的半径
-
-
SWITCHING SYSTEM
DESCRIPTION
When the coil tap switch is in neck position, coil tap is on. When the coil tap switch is in bridge position, coil tap is off. When coil tap is off and the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is in the center position, both neck and bridge pickups are selected. When the switch is in the bridge position, the bridge pickup is selected. When coil tap is on and the pickup selector switch is in the neck position, the bridge side of the neck pickup is selected. When the switch is in center position, the bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, neck side of the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
当吉他保持在弹奏位置时,琴体下部靠近膝盖附近有一个三向拾音器选择开关。 有一个push/pull音量旋钮,它也控制fishman fluence voicing的功能,还有一个切单开关和位于琴体末端的音色旋钮。 当音量旋钮调低时使用 fluence voice 1,音量旋钮调高时会使用 fluence voice 2。
-
OTHERS
Features

Wizard III 5拼枫木/胡桃木琴颈
Ibanez 薄、平、顺滑的 Wizard 琴颈坚固耐用,具有无限的可玩性,并配有两个八度的 24 品指板,可提供宽广的音调范围。

乌木指板
乌木可产生紧密的低音和中音,在高音部分具有强大的音头,并具有快速的响应和丰富的延音。

大号品丝
大号品丝有助于提高演奏的流畅度,尤其是单音演奏。

椿茶木琴体
使用椿茶木作为琴体木材,可产生丰富的中低音。

Fishman® Fluence™ Modern Humbucker Alnico / Fluence™ Modern Humbucker Ceramic 拾音器
Fishman® Fluence™ Modern Humbucker 拾音器提供强劲的音色和强大的音头,而没有多余的噪音。

Edge-Zero II 颤音琴桥
Edge-Zero III 琴桥设计具有较低位置的颤音器,可提供舒适的演奏,并具有螺柱锁功能,可实现稳定的调音。

切单开关
切单开关为两个拾音器增加了声音和音调的变化。

Fishman® Fluence™ Voicing开关 (拉提音量旋钮)
Voicing开关可使拾音器从现代、有源高输出声音切换到清脆、干净、流畅的声音。

夜光侧圆点镶嵌
夜光侧圆点标记使演奏者在黑暗的舞台上表演时很容易看到指板位置。
