RG652AHMFX
- NGB : 脉状星云绿色渐变
- RPB : 高贵绛紫色渐变
- COLOR VARIATION：
SPEC
-
SPEC
- neck type
- Super Wizard HP5拼枫木/胡桃木琴颈
- top/back/body
- 梣木琴体
- fretboard
- 包边雀眼枫木指板黑色圆点镶嵌
- fret
- 大号品丝
- number of frets
- 24
- bridge
- Gibraltar Standard III 琴桥
- string space
- 10.8mm
- neck pickup
- DiMarzio® Air Norton™ (双) 琴颈拾音器被动/Alnico
- bridge pickup
- DiMarzio® The Tone Zone® (双) 琴桥拾音器被动/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- nut
- Graph Tech® BLACK TUSQ XL®琴枕
- hardware color
- 宇宙黑硬件
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 17mm at 1F
- d : Thickness
- 19mm at 12F
- Radius :
- 430mmR
-
DESCRIPTION
吉他颈部图
a: 上琴枕部位的指板宽度
b: 指定品位的指板宽度
c: 第一品位的琴颈厚度
d: 指定品位的琴颈厚度
Radius: 指板曲面的半径
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
当吉他保持在演奏位置时，琴体的下边缘有一个旋钮和一个开关。 最靠近琴颈的是五向拾音器选择器开关。 靠近输入插孔的是音色旋钮。 音量旋钮位于五向拾音器选择开关的上方。
-
OTHERS
Features
Super Wizard 5拼 枫木/胡桃木琴颈
Super Wizard 5pc 枫木/胡桃木琴颈使演奏更加顺畅。
梣木琴体
梣木琴体具有令人愉悦的亮度和丰富的延音。
雀眼枫木指板
雀眼枫木带独特的木纹和从低频到高频具有均衡的音色特征。
Gibraltar Standard III 琴桥
Gibraltar Standard III 琴桥采用重新设计的底板和琴码，可增强演奏舒适度同时确保最佳的琴弦振动传递。
Gotoh® MG-T 带锁弦钮
Gotoh®MG-T带锁弦钮实现了令人难以置信的调音稳定性，减少了换弦时间。
