RG565R
SPEC
-
SPEC
- neck type
- Super Wizard5拼枫木/胡桃木琴颈
- top/back/body
- 椴木琴体
- fretboard
- 包边玫瑰木指板鲨鱼牙白色镶嵌
- fret
- 大号品丝
- number of frets
- 24
- bridge
- Edge 颤音琴桥
- string space
- 10.8mm
- neck pickup
- Infinity R (双) 琴颈拾音器被动/陶瓷
- bridge pickup
- V8 (双) 琴桥拾音器被动/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- 黑色硬件
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 17mm at 1F
- d : Thickness
- 19mm at 12F
- Radius :
- 430mmR
-
DESCRIPTION
吉他颈部图
a: 上琴枕部位的指板宽度
b: 指定品位的指板宽度
c: 第一品位的琴颈厚度
d: 指定品位的琴颈厚度
Radius: 指板曲面的半径
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is active. When the switch is in between neck and center position, the neck pickup is in active and in parallel. When the switch is in center position, the neck and bridge pickups are active. When the switch is in between center and bridge position, the bridge side of the neck pickup and the neck side of the bridge pickup are active. When the switch is in bridge position, the bridge pickup is active.
-
CONTROLS
DESCRIPTION
当吉他保持在演奏位置时,琴体的下边缘有一个旋钮和一个开关。 最靠近琴颈的是五向拾音器选择器开关。 靠近输入插孔的是音色旋钮。 音量旋钮位于五向拾音器选择开关的上方。
-
OTHERS
Features

Super Wizard 5拼枫木/胡桃木琴颈
Super Wizard 5拼枫木/胡桃木琴颈可提供格外顺滑的演奏。

玫瑰木指板
玫瑰木指板提供均衡的音色和集中的中音。

大号品丝
大号品丝有助于提高演奏的流畅度,尤其是单音演奏。

椴木琴体
椴木琴体发出自然、平缓的音调。

Infinity R / V8 拾音器
Ibanez Infinity 拾音器可产生准确、紧凑的声音,并具有出色的动态效果。即使在重音设置下,也不会损失音调清晰度。

Gotoh® 弦钮
Gotoh® 弦钮提供卓越的精度、平滑的感觉和出色的调音精度。

Edge 颤音琴桥
杰作 Edge 琴桥提供卓越的调音稳定性、精确的音调调整和演奏舒适度。
