RG460DX
SPEC
-
SPEC
- neck type
- Wizard III枫木琴颈
- top/back/body
- 柳安木琴体
- fretboard
- 孪叶苏木指板鲨鱼牙镶嵌
- fret
- 大号品丝
- number of frets
- 24
- bridge
- Edge-Zero II 颤音琴桥
- string space
- 10.8mm
- neck pickup
- Quantum (单) 琴颈拾音器被动/Alnico
- middle pickup
- Quantum (单) 中部拾音器被动/Alnico
- bridge pickup
- Quantum (双) 琴桥拾音器被动/陶瓷
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- 黑色硬件
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 24F
- c : Thickness
- 19mm at 1F
- d : Thickness
- 21mm at 12F
- Radius :
- 400mmR
-
DESCRIPTION
吉他颈部图
a: 上琴枕部位的指板宽度
b: 指定品位的指板宽度
c: 第一品位的琴颈厚度
d: 指定品位的琴颈厚度
Radius: 指板曲面的半径
-
-
SWITCHING SYSTEM
DESCRIPTION
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, the neck pickup and the center pickup are selected. When the switch is in center position, center pickup is selected. When the switch is in between the center and bridge position, center pickup and the neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.
-
CONTROLS
DESCRIPTION
当吉他保持在演奏位置时,琴体的下边缘有一个旋钮和一个开关。 最靠近琴颈的是五向拾音器选择器开关。 靠近输入插孔的是音色旋钮。 音量旋钮位于五向拾音器选择开关的上方。
-
OTHERS
Features

单声道输出插孔
单声道输出插孔由坚固耐用的材料制成,并且是一体式的,以避免插孔发生不必要的移动和松动,从而导致接触故障或断开连接。 这种创新设计允许用户长时间的享受演奏和进行最少必要的维护。

孪叶苏木指板
孪叶苏木呈红棕色,可产生丰富的中音和清脆的高音。

Edge-Zero II 颤音琴桥
Edge Zero II 琴桥的高度较低,可增强弹奏舒适性,并具有螺柱锁定功能,可确保调弦稳定性。

Wizard III 枫木琴颈
Ibanez 的 Wizard 琴颈具有纤薄、平坦、稳固、强度大且耐用的特点,可为“暴力型”乐手提供绝佳的可弹奏性,并具有 24 品双八度指板,可提供更宽广的音色范围。

Quantum S-S-H 拾音器
Quantum 拾音器提供快速的低音响应,可实现高速断音即兴演奏的快速反馈,具有强大的中音和精确的高音音调。

柳安木琴体
柳安木琴体提供圆润的中音和甜美的音调。
