RGMS7

RGMS7-BK
  • BK : Black
  • COLOR VARIATION：

Top of the RGMS7-BK's body
Back of the RGMS7-BK's body
Entire top of the RGMS7-BK
RG

SPEC

  • SPECS

    • neck type
      Wizard III-7 for Multi Scale5pc Maple/Walnut neck
    • top/back/body
      Nyatoh body
    • fretboard
      Jatoba fretboardWhite Step off-set dot inlay
    • fret
      Jumbo frets
    • number of frets
      24
    • bridge
      Mono-rail bridge
    • string space
      10.8mm
    • neck pickup
      Array 7 MS (H) neck pickupPassive/Ceramic
    • bridge pickup
      Array 7 MS (H) bridge pickupPassive/Ceramic
    • factory tuning
      1E,2B,3G,4D,5A,6E,7B
    • strings
      D'Addario® EXL120+.059
    • string gauge
      .009/.011/.016/.024/.032/.042/.059
    • hardware color
      Cosmo Black

  • NECK DIMENSIONS

      • Scale :
        686mm - 648mm/27" - 25.5"
      • a : Width
        48mm at NUT
      • b : Width
        68mm at 24F
      • c : Thickness
        19mm at 1F
      • d : Thickness
        21mm at 12F
      • Radius :
        400mmR

    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the fret position specified by the neck dimension
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the fret position specified by the neck dimension
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    RGMS7's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.

  • CONTROLS

    RGMS7's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

  • OTHER FEATURES

Features

Mono-rail bridge

Mono-rail bridge

Designed for both stability and sustain, the innovative Ibanez Mono-Rail bridge minimizes cross-talk between strings

Jatoba Fretboard

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.

Array-7 MS pickups

Array-7 MS pickups

Ibanez Array pickups deliver a super tight tone with low noise that handle down-tuning perfectly.

Multi Scale Neck

Multi Scale Neck

The multi-scale neck utilizes an equalized string tension, creating a more “open” or “alive” tone that not only expands harmonic complexity, but also offers a more comfortable playing experience.
