RG752AHM-RPB
  • RPB : Royal Plum Burst
  • COLOR VARIATION:
SHARE:
RG

SPEC

  • SPECS

    • neck type
    • Wizard-75pc Maple/Wenge neck
    • top/back/body
    • Ash body
    • fretboard
    • Bound Birdseye MapleBlack dot inlay
    • fret
    • Jumbo frets
    • bridge
    • Lo-Pro Edge 7 tremolo bridge
    • string space
    • 10.8mm
    • neck pickup
    • DiMarzio® PAF® 7 (H) neck pickupPassive/Ceramic
    • bridge pickup
    • DiMarzio® PAF® 7 (H) bridge pickupPassive/Ceramic
    • factory tuning
    • 1E, 2B, 3G, 4D, 5A, 6E, 7B
    • string gauge
    • .009/.011/.016/.024/.032/.042/.054
    • hardware color
    • Cosmo black
  • NECK DIMENSIONS

      • Scale :
      • 648mm/25.5"
      • a : Width
      • 48mm at NUT
      • b : Width
      • 68mm at 24F
      • c : Thickness
      • 19mm at 1F
      • d : Thickness
      • 21mm at 12F
      • Radius :
      • 430mmR
    • DESCRIPTION

      Guitar Neck Diagram
      a: Width of the neck at the nut
      b: Width of the neck at the first fret
      c: Thickness of the neck at the first fret
      d: Thickness of the neck at the twelfth fret
      Radius: Radius of the fingerboard

  • SWITCHING SYSTEM

    RG752AHM's Switching system diagram

    DESCRIPTION

    When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is between neck and center position, the neck humbucker is selected and is in parallel. When the switch is in center position, both neck and bridge pickups are selected. When the switch is in between center and bridge position, bridge side of the neck pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected.

  • CONTROLS

    RG752AHM's control diagram

    DESCRIPTION

    With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

  • OTHER FEATURES

    • Hardshell case included

Features

DiMarzio® PAF7 pickups

DiMarzio® PAF®7 pickups

The DiMarzio® PAF®7 pickups produce a sound that's both clean and open on the low notes and warm and rounded on the high ones.

Birdseye Maple Fretboard

Birdseye Maple Fretboard

Birdseye Maple has a unique wood grain and features a well-balanced tonal character from low to high end.

Lo-Pro Edge tremolo bridge

Lo-Pro Edge tremolo bridge

The legendary Lo-Pro Edge bridge offers maximum playing comfort with its streamlined profile and recessed fine tuners. Locking studs contribute to tuning stability.

Wizard-7 Neck

Wizard-7 Neck

Slim, fast and durable Wizard-7 5pc Maple/Wenge neck
