PCBE12MH 06
- OPN : Open Pore Natural
- COLOR VARIATION：
SHARE：
ACOUSTIC BASS
SPEC
-
SPECS
- body shape
- Grand Concert body
- top
- Sapele top
- back & sides
- Sapele back & Sapele sides
- neck
- PCBE Maple neck
- fretboard
- Nandu Wood fretboard
- bridge
- Nandu Wood bridge
- inlay
- White dot
- soundhole rosette
- Tortoiseshell
- tuning machine
- Chrome Die-cast Tuners
- nut material
- Plastic
- number of frets
- 20
- saddle material
- Plastic
- bridge pins
- Black with white dot
- strings
- Ibanez IABS4XC32 Carbon coated
- string gauge
- .040/.060/.075/.095
- string space
- 19mm
- factory tuning
- 1G,2D,3A,4E
- pickup
- Ibanez Undersaddle
- preamp
- Ibanez AEQ-2T preamp w/Onboard tuner
- output jack
- 1/4" output
-
NECK DIMENSIONS
-
- Scale :
- 812.8mm
- a : Width
- 43mm at NUT
- b : Width
- 58mm at 14F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 23.5mm at 7F
- Radius :
- 400mmR
-
-
-
BODY DIMENSIONS
-
- a : Length
- 19 1/4"
- b : Width
- 15 1/4"
- c : Max Depth
- 4 1/4"
-
-
-
PREAMP
-
OTHER FEATURES
- Recommended Case
-
SGBE50C
Features
Ibanez AEQ-2T preamp w/Onboard tuner
AEQ-2T preamp is specifically-designed to adjust the frequencies of a bass and Treble, and allows operation of the built-in tuner without the instrument being plugged in.
