GVB36
SPEC
-
SPECS
- neck type
- GVB3pc Maple neck
- top/back/body
- Flamed Maple topAlder body
- fretboard
- Rosewood fretboardAbalone oval inlay
- fret
- Medium frets
- number of frets
- 24
- bridge
- MR4 bridge
- string space
- 14mm
- neck pickup
- Bartolini® MK-1 neck pickupPassive
- bridge pickup
- Bartolini® MK-1 bridge pickupPassive
- equaliser
- EQB-IIISP 3 band EQ w/ Mid frequency selector (push/pull)
- factory tuning
- 1C,2G,3D,4A,5E,6B
- strings
- D'Addario® EXL
- string gauge
- .032/.040/.060/.080/.100/.125
- hardware color
- Cosmo black
-
NECK DIMENSIONS
-
- Scale :
- 864mm/34"
- a : Width
- 54mm at NUT
- b : Width
- 72.5mm at 24F
- c : Thickness
- 19.5mm at 1F
- d : Thickness
- 21.5mm at 12F
- Radius :
- 305mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
CONTROLS
DESCRIPTION
There are two groups of knobs on this bass. With the bass held in the playing position, there are three smaller knobs closest to the lower edge of the body. From the lower bout towards the neck they are treble boost/cut, mid boost/cut, and bass boost/cut. The other group of knobs are closer to bridge. The knob closest to the input jack is the pickup balancer, and the knob closest to the neck is the volume knob. When the mid-range knob is down, the mid boost peak is at 250hz, when the knob is pulled up, the mid boost peak is at 60 hz.
-
OTHER FEATURES
