  • LGS : Natural Low Gloss
  • WK : Weathered Black Open Pore
  • COLOR VARIATION:
SHARE:
AE

SPEC

  • SPECS

    • body shape
    • AE body
    • bracing
    • Standard X-M Bracing
    • top
    • Solid Okoume top
    • back & sides
    • Okoume back & Okoume sides
    • neck
    • Comfort Grip w/Rounded Fretboard EdgeNyatoh neck
    • fretboard
    • Katalox fretboard
    • bridge
    • Katalox Scalloped Bridge
    • inlay
    • Specially designed Wooden Vine inlay
    • soundhole rosette
    • Abalone and Wooden
    • tuning machine
    • Chrome Die-cast tuners(1:18 gear ratio)
    • nut material
    • Bone
    • number of frets
    • 20
    • saddle material
    • Compensated Bone
    • bridge pins
    • Ibanez Advantage™
    • strings
    • D'Addario® XTAPB1152
    • string gauge
    • .011/.015/.022/.032/.042/.052
    • string space
    • 11mm
    • factory tuning
    • 1E,2B,3G,4D,5A,6E
    • pickup
    • Ibanez AP11 Magnetic Pickup
    • preamp
    • Ibanez Custom Electronics w/ Volume and Tone Control
    • output jack
    • 1/4" Endpin Jack
  • NECK DIMENSIONS

      • Scale :
      • 651mm
      • a : Width
      • 44mm at NUT
      • b : Width
      • 55mm at 14F
      • c : Thickness
      • 20mm at 1F
      • d : Thickness
      • 21mm at 7F
      • Radius :
      • 400mmR
  • BODY DIMENSIONS

      • a : Length
      • 20 "
      • b : Width
      • 16 1/8"
      • c : Max Depth
      • 4 5/8"
  • PREAMP

  • OTHER FEATURES

Features

Standard X-M Bracing

Standard X-M Bracing

Spending a few years with trial and error, Ibanez finally reached to out-of-the-box X-M Bracing to generate the ultimate sound standing out on the stage. The carefully designed scalloped X-bracing, the allocation of tone braces and finger braces transmit the string vibration efficiently through the bridge to the body. The X-M Bracing creates the clear bottom and crispy treble sound with trimmed warm mid-range, yet providing wide dynamic range and highly response.

AE body shape

AE body shape

Designed for projection, balance, and comfort, the AE's perfectly crafted contemporary body shape offers the best of all worlds.

Ibanez AP11 Magnetic Pickup

Ibanez AP11 Magnetic Pickup

The newly designed AP11 pickup is small, lightweight, and positioned so it won’t inhibit the natural vibrations of the top wood. The pickup generates a highly responsive sound with minimal feedback and delivers a lively response throughout the entire frequency range. The sound is transparent and reflects the guitar’s natural acoustic tone while preserving presence and mid-range. The AP11 also works well with effects such as reverb, chorus, and many others.

Ibanez Custom Electronics w/ Volume and Tone Control

Ibanez Custom Electronics w/ Volume and Tone Control

The guitar also features on-board treble and bass controls for contouring the tone, making the AE suitable for variety of applications for modern players.

Scalloped Bridge

Scalloped Bridge

The light-weight Scalloped Bridge helps improving the vibration efficiency of the top board for better resonance, as well as giving more flexible string action adjustment.

Comfort Grip w/Rounded Fingerboard Edge

Comfort Grip w/Rounded Fingerboard Edge

In order to achieve supreme playability, the neck was specially designed with Thin-C shape style comfort grip with fingerboard's rounded edge.

Jumbo Frets

Jumbo Frets

The jumbo frets support easy fingering.

Ibanez Advantage bridge pins

Ibanez Advantage™ bridge pins

These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
