PF15 05


- BK : Black High Gloss
- NT : Natural High Gloss
- COLOR VARIATION:
SHARE:
PF
SPEC
-
SPECS
- body shape
- Dreadnought body
- top
- Spruce top
- back & sides
- Okoume back & Okoume sides
- neck
- PF Nyatoh neck
- fretboard
- Laurel fretboard
- bridge
- Laurel bridge
- inlay
- White dot
- soundhole rosette
- Black & White multi
- tuning machine
- Chrome Die-cast Tuner
- nut material
- Plastic
- number of frets
- 20
- saddle material
- Plastic
- bridge pins
- Ibanez Advantage™
- strings
- Ibanez IACS6C
- string gauge
- .012/.016/.024/.032/.042/.053
- string space
- 11mm
- factory tuning
- 1E,2B,3G,4D,5A,6E
-
NECK DIMENSIONS
-
- Scale :
- 648mm
- a : Width
- 42mm at NUT
- b : Width
- 54mm at 14F
- c : Thickness
- 21mm at 1F
- d : Thickness
- 22.5mm at 7F
- Radius :
- 240mmR
-
-
-
BODY DIMENSIONS
-
- a : Length
- 20 "
- b : Width
- 15 3/4"
- c : Max Depth
- 5"
-
-
-
OTHER FEATURES
- Recommended Case
-
FS40DA
Features

Ibanez Advantage™ bridge pins
These pins really are an advantage over old-fashioned pins. Advantage™ pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage™ the pin and string stay put.
