JS2GD
SPEC
-
SPECS
- neck type
- JS1pc Maple neck
- top/back/body
- Alder body
- fretboard
- Rosewood fretboardMother of Pearl dot inlay
- fret
- Jescar EVOgold™ fretsPrestige fret edge treatment
- number of frets
- 22
- bridge
- Edge bridge
- string space
- 10.8mm
- neck pickup
- DiMarzio® Satch Track™ (H) neck pickupPassive/Ceramic
- middle pickup
- DiMarzio® Satch Track™ (H) middle pickupPassive/Ceramic
- bridge pickup
- DiMarzio® FRED® (H) bridge pickupPassive/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL120
- string gauge
- .009/.011/.016/.024/.032/.042
- nut
- Locking nut
- hardware color
- Gold
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 42.8mm at NUT
- b : Width
- 56.4mm at 21F
- c : Thickness
- 20mm at 1F
- d : Thickness
- 22.3mm at 12F
- Radius :
- 250mmR
-
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
-
-
SWITCHING SYSTEM
DESCRIPTION
When the tone knob is pulled up, the coil tap is engaged. When the tone knob is down, the coil tap is disengaged. Coil tap disengaged: When the neck pickup selector switch is in the down position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the up position, the neck pickup is selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the up position, the neck pickup and the center pickup are selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the up position, the center pickup is selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the down position, the center pickup and the bridge pickup are selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the down position, the bridge pickup is selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the down position, the neck pickup and the bridge pickup are selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the down position, the neck pickup, the center pickup and the bridge pickup are selected. Coil tap disengaged: When the neck pickup selector switch is in the down position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the up position, the neck pickup is selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the up position, the neck pickup and the center pickup are selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the up position, the center pickup is selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the down position, the center pickup and the bridge pickup are selected. When the neck pickup selector switch is in the up position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the down position, the bridge pickup is selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the up position and the bridge pickup selector switch is in the down position, the neck pickup and the bridge pickup are selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the down position, the neck pickup, the center pickup and the bridge pickup are selected. When the neck pickup selector switch is in the down position, the center pickup selector switch is in the down position and the bridge pickup selector switch is in the down position, the neck pickup, the center pickup and neck side of the bridge pickup are selected.
-
CONTROLS
DESCRIPTION
With the guitar held in the playing position, there are three mini toggle switches along the lower edge of the body. The switch closest to the knee cutout is the neck pickup selector switch. The center switch is the center pickup selector switch, and the switch closest to the end of the body is the bridge pickup on/off switch. There are also two knobs more towards the center of the guitar. The knob closest to the end of the body is the tone control, and the knob closest to the neck is the volume control. The tone control has a push/pull function which acts as a coil tap on the bridge pickup. The volume knob also features a push/pull function for activating the high pass filter. Both functions activate with their respective knobs pulled up.
-
OTHER FEATURES
- Recommended Bag
-
IGB724-BK
- Gotoh® machine heads
- Hi-pass filter on volume control (push/pull)
- Coil-tap switch on tone control (push/pull)
- Hardshell case included
Features
Maple neck
The Maple neck provides stability and bright tonal character.
Rosewood fretboard
Rosewood fretboard provides a well-balanced solid tone with a focused mid range.
Alder body
The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.
DiMarzio® Satch Track™ / FRED® pickups
The DiMarzio® Satch Track™ is Joe's first single-coil size signature pickup. Combined with FRED®, they offer focused sound and great versatility.
Gotoh® machine heads
Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.
Edge tremolo
The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.
High-Pass filter on volume control
A high pass filter on the volume pot maintains highs at low volumes.
Coil-tap switch on tone control (push/pull)
The push/pull coil tap adds sound and tonal variations for pickups.
Ultralite Tremolo Arm™ included
The Ultralite Tremolo Arm™ achieved a significant reduction in weight by utilizing Carbon Graphite for the grip, resulting in less interaction with strings and more sensitive control of the tremolo arm movement.
